What we install
The right components.
You don’t have to compare spec sheets. Our engineers already have. Every Emit Solar system uses proven components, selected for how well they work together and how reliably they perform over time.
Tap any part to see what it does, why we chose it and what covers it.
Emit Solar System · roof to grid
tap to expand
Solar Panels
Solar Inverter
Battery Add On
Solar DB
Smart PV Meter
EV Expansion Add On
Home DB
Home Appliances
TNB Grid
Solar Panels
On your roof
Solar Inverter
DC to AC
Battery
Optional add on
Solar DB
Safety components
Smart PV Meter
Measures import and export
EV Expansion
Optional add on
Home DB
Already there · house circuits
TNB Grid
Already there · export at RM0.27 – RM0.37
Installed by Emit
Existing home setup
Optional add-on
Tap any part to read about it.
Pink = installed by Emit. Dashed = optional add-on. Grey = your existing supply. Tap any part to read about it.
Solar Panels
AIKO panels. ABC technology.
We use 670W AIKO ABC N-Type panels. With All Back Contact technology, the electrical contacts – the silver lines that normally run across the front of the panel – are moved to the back, freeing up more surface area to capture sunlight.
More working surface
•Up to 24.8% efficiency
•More cell area exposed to sunlight
•Designed to perform well in hot climates
Better in partial shade
•Conventional panels can lose more output when part of the panel is shaded
•AIKO’s cell design helps limit that loss
•Satellite dishes, vents and passing clouds have less impact on generation
More from your roof
•670W output per panel
•Fewer panels needed for the system your home needs
•Better use of roof space
AIKO warranty & spec
PRODUCT
15 years
PERFORMANCE
30 years
EFFICIENCY
24.8%
Solar Inverter
Huawei. The market leader.
High efficiency, intelligent monitoring and advanced safety features in one integrated platform. Battery-ready from day one, so storage can be added later without replacing the inverter or rewiring the system.
Efficient conversion
•Up to 98.6% peak efficiency
•Minimises energy lost during conversion
•Designed for reliable everyday operation
Smart monitoring
•Tracks your system throughout the day
•Alerts us when something doesn’t look right
•Helps us troubleshoot issues remotely
Smart power management
•Balances power across a three-phase supply
•Helps direct solar electricity to where it’s needed
•Increases how much of your solar electricity you can use
Huawei warranty & spec
PRODUCT
10 years
PEAK EFFICIENCY
98.6%
ARC PROTECTION
AI-driven
Solar Inverter
Solis. Smart hybrid value.
A flexible hybrid inverter that gives you smart monitoring, battery-readiness and future backup options at a more accessible price point.
Efficient conversion
•Up to 97.5% peak efficiency
•Makes efficient use of the energy your panels generate
•Built for everyday residential use
Smart monitoring
•Tracks and manages your system through SolisCloud
•Alerts and system data help identify issues
•Remote troubleshooting makes support easier
Flexible solar + storage
•Battery-ready
•Works with a range of compatible low-voltage batteries
•Can support backup and smart load management when paired with the appropriate battery setup
Solis warranty & spec
PRODUCT
10 years
PEAK EFFICIENCY
97.5%
PROTECTION
IP66-rated
Battery systemOptional
Store before you export.
A battery stores excess solar electricity before exporting it at a lower value. Use it when your panels aren’t generating and buy less electricity from the grid at the full retail tariff. Add one when you install your system or later, depending on how your home uses electricity.
Store excess solar electricity
•Keep excess daytime solar
•Use it when your panels aren’t generating
•Export only what is leftover
Buy less later
•Use stored solar electricity in the evening or at night
•Reduce how much electricity you buy from the grid
•Get more value from the solar you generate
Add when you’re ready
•Add a battery now or in the future
•Your inverter is battery-ready from day one
•DC- and AC-coupled options supported
Solar distribution board
Solar DB. Safety built in. EV-ready when you are.
The Solar DB connects your solar system to your home and the TNB grid. It brings the required protection together in one place and is purpose-built for future EV expansion.
Single-line · AC side
Solar Panels
Roof-mounted
↓
Solar Inverter
DC → AC
↓
Solar DB
Safety components
↓
Home DB
House circuits · TNB supply
EV expansion
Safe grid connection
Connects your solar system to your home electrical system and the TNB grid.
Compliant with regulations
Includes the required protection including a surge protection device (SPD).
One-switch isolation
A dedicated switch lets you disconnect the system from your home when needed.
SIRIM-certified components
Built with SIRIM-certified electrical components for added safety and reliability.
IP66-rated enclosure
A durable, weather-resistant enclosure protects the electrical components from dust and water.
EV-ready by design
Designed for an easy future EV upgrade, with the Expansion Box and required protection added when needed.
INCLUDED AS STANDARD
10mm² cabling for future EV expansion
Installed from day one and sized for future EV charging. When you’re ready, add the purpose-built EV Expansion DB and your own EV charger.
22kW
On a 3-phase supply
RM0
Additional charge – included in our standard installation
The EV Expansion and the charger is a separate add on.
Smart PV Meter
Three numbers. Basic systems only show you one.
Our Smart PV Meter is included as standard, so you can see what your system generates, what your home imports from TNB and what you export back to the grid.
Today · your home
Live
GENERATION
28.4kWh
What your panels made
Basic system view
EXPORT
11.2kWh
Sent to the grid
Included with Emit
IMPORT
6.8kWh
Bought from TNB
Included with Emit
Used directly in the house
17.2 kWh
— the kWh worth the most to you
Included as standard
•Smart PV Meter with every installation
•Connected to your home DB
•Tracks grid import and export
Use more of your solar
•See when you’re exporting excess solar electricity
•Shift flexible usage into those hours
•Use more solar directly and save at the full retail rate instead of exporting at a lower value
See the full picture
•See how your home uses electricity
•Generation, import and export in one place
•Basic systems only show generation
EV Expansion BoxOptional
Add EV charging without starting over.
Your Emit solar system is designed with future EV charging in mind. The Solar DB and 10mm² cabling are already in place, so adding an EV charger later is simpler and cleaner.
Easy integration
Connects seamlessly with the Solar DB, making EV charger installation simpler and cleaner.
Dedicated EV protection
Houses the required safety and protection components that protect your EV, home and electrical system.
Safety compliant
Meets applicable Suruhanjaya Tenaga requirements, policies and regulations for residential EV charging.
Now
Solar Panels
How we choose
Every component must pass three tests before we stand behind them.
A
Meets the right standards
SIRIM, Suruhanjaya Tenaga, TNB and Solar ATAP rules.
B
Tier-1 ranked, local support
Established manufacturer, with local support, stock and after-sales capability.
C
Proven track record
Products with real-world performance in climates like ours.
Backed by Emit
A good system is more than good components.
We stand behind every system we install, with our own warranties and support on top of the manufacturer’s warranties. If anything needs attention, you deal with us.
Emit warranty
WORKMANSHIP
1 year
SYSTEM FUNCTIONALITY
2 years
Manufacturer terms are set by Aiko, Huawei and Solis and vary by model. Emit Solar warranties commence from the installation date and terms and conditions apply. Exact terms for your system are listed in your quote.
REGISTRATION OF INTEREST
Get an instant quote and
a free home assessment.
a free home assessment.
Tell us where you live and your monthly TNB bill.
1
See your initial system size, monthly payment and estimated savings.
2
Book a free home visit to confirm it. No deposit, no obligation.
3
Get your final proposal
Prefer to talk?
FAQs
Frequently asked questions
How does a solar pv system work?+
Solar panels convert sunlight into DC electricity. Your inverter converts this to AC power your home uses. During daylight hours, you use solar first – reducing what you draw from TNB. Surplus is exported to TNB via Solar ATAP for bill credits.
What type of inverter do you install?+
We primarily install hybrid string inverters that are efficient, easy to monitor and battery-ready if you want to add storage later.
Do you offer battery storage?+
- Battery storage is offered as an optional add-on because of its high cost, and not every household benefits equally from it.
- By making it optional, you have the flexibility to decide whether the additional investment makes sense for your usage pattern and budget.
- This also allows you to install your solar system first and decide later if you’d like to add batteries once you better understand your Solar Electricity consumption patterns.
Do I need a battery?+
- Not necessarily. With Malaysia’s current tariff structure, the Solar ATAP scheme, and the high cost of batteries, adding a battery may not significantly increase savings for most homeowners.
- You can already save by using the Solar Electricity your system generates directly during the day.
- Under Solar ATAP, you’ll also be able to export any excess Solar Electricity for additional savings on your TNB bill.
Does installing a battery system mean I will have electricity during blackouts?+
Yes, if you opt to include a backup power box that can help keep essential appliances running during blackouts.
Does your system support EV charging?+
Yes. Our system is designed to support future EV charging with 10mm2 cabling pre-installed and the option to add an EV Expansion Box when you’re ready to install a charger.
